..	Isuzu 8,000 Watt Diesel Generator

Visit my Store 8,000 Watt | 12,500 Watt | 14,000 Watt

Isuzu Powered 8 kW Diesel Generator - This Isuzu 800TS "Super Compact Series" diesel generator is suitable for continous use and with its ultra compact design is perfect for installing in a bus or coach conversion!

Prime Power.
Built to run 24 hours a day.

This brawny little three cylinder set has plenty of power to run your home, job site or business. This unit includes an Isuzu 3CB 3 cylinder 1800 RPM diesel engine, replaceable cylinder liners, brushless generator end, liquid cooling, muffler, cool flow radiator w/ fan guards (pushor fan), replaceable foam air filter elemant, steel channel base, automatic voltage regulation, fast-acting glow plugs for cold starting, auto shutdowns for low oil/high water temperature, turn-key electric start and is rated for over 30,000 hours use.

Installation Data

Electrical Specifications			-
Automatic Voltage Regulator			Standard
Voltage Regulation (No Load to Full Load)			1%
Power Single-Phase			---
Maximum Output			8,500 watts
Continous Output			8,000 watts
Load Amperage at 120 volts			---
Maximum Load			71 Amps
Continous Load			67 Amps
Load Amperage at 240 volts			---
Maximum Load			35 Amps
Continous Load			33 Amps
Sound Level @ 23 ft(7 m) at full load			71 dB(A)

Installation Data

Model			Isuzu 3CB
Type			Vertical In-Line, Indirect Injection
Horsepower			14 HP
Displacement			1.1 Liters
Oil Capacity (w/ Oil Filter)			Approx. 4.8 qts
RPM			1800
Cylinders			3
Cylinder Block			Cast Iron w/ Cast Iron Sleeves
Bore & Stroke			3.05 x 3.14 in.
Cooling			Liquid-Cooling, Pushor Fan
Coolant Capacity			Approx. 6.5 Qts
Fuel			No. 2 Diesel
Electric Fuel Pump			12 V - Standard
Cold Weather Starting Aid			Glow Plugs
Starting System			Electric

Installation Data

Consumption at 1/2 load			0.4 gallons/hour
Consumption at 3/4 load			0.61 gallons/hour
Consumption at full load			0.82 gallons/hour

Control Panel

Key Start			Standard
Engine Preheat			Standard
Circuit Breaker			10 Amps - Resetable

Installation Data

Fuel Inlet Hose Size			3/8"
Fuel Return Hose Size			5/16"
Power Lead Size			No. 4 AWG
No. Power Lead Conductors			4
Exhaust Outlet			2" OD Muffler Outlet
Coolant Recommendation			Mixture: 1/2 Anti-Freeze & 1/2 Water
Battery Requirement			12 VDC - 525 CCA
Engine Oil Requirement			10w-30 Synthetic
Air Flow Direction (Facing Radiator)			Inlet: Back-Side Outlet: Front-Side
Exhaust Direction (Facing Radiator)			Right-Side
Fuel Inlet Direction (Facing Radiator)			Left-Side
Oil Fill/Dipstick (Facing Radiator)			Left-Side
Power Output Direction (Facing Radiator)			Back-Side

Warranty

Engine Warranty			2 Years
Generator Warranty			1 Year
100% Coverage for Parts & Labor			Standard

Dimensions

Length			36 inches
Width			20 inches
Height			28 inches
Dry weight			665 lbs
